Vinco 1.5KW Single Phase Borehole Motor
The Vinco 1.5KW 1ph Borehole Motor is designed for efficiency and durability, ideal for various borehole and well applications. Made in Italy, this motor is crafted with high-quality materials to ensure reliable performance and a long service life. It is built to pair seamlessly with standard borehole pumps and is suitable for both residential and industrial water solutions.
Key Features:
- High-Performance Design: A liquid-cooled, 2-pole asynchronous squirrel-cage motor with stainless steel construction, offering outstanding durability in submerged applications.
- Efficient Operation: With a power output of 1.5KW, this motor provides optimal energy efficiency and can operate under high thrust loads, supporting a maximum thrust load of 4500N.
- Corrosion-Resistant Build: Equipped with IP68 protection, heavy-duty bearings, and a reinforced rubber diaphragm, the motor is engineered to withstand high sand content and challenging water conditions.
- Thermal Protection and Reliability: High-grade 220°C-lacquered copper windings and cold-rolled silicon steel lamination ensure excellent insulation and heat resistance, while the mechanical sealing system enhances performance in sandy environments.
- Standard Compatibility: The motor features NEMA-standard splines, allowing it to easily pair with compatible borehole pumps.
Specifications:
- Power Output: 1.5KW (2.0 HP)
- Motor Diameter: 4 inches
- Voltage: Available in both single-phase (220V) and three-phase (380V) options
- Operating Temperature: Max ambient temperature of 35°C
- Protection Features: Requires a DOL starter or specialized control box for overload, dry running, and power fluctuation protection.
The Vinco 1.5KW 1ph Borehole Motor is a premium choice for customers needing a reliable, efficient, and long-lasting motor for borehole systems. It is designed to meet high standards of performance, providing peace of mind and value for a wide range of applications.
